"PIOCELAN utilizes proprietary polymer hybrid technology, enabling the adjustment of various physical properties to meet a wide range of application requirements. We offer several product series, including the O series and S series. The O series is suitable for a variety of structural applications and provides excellent impact absorption performance. It is widely used in applications such as automotive impact energy absorbers. This series also includes the E type, featuring smaller bead sizes for molding complex foam part geometries, and the NS type, which offers permanent antistatic performance for electrostatic-sensitive applications such as electronic component transport containers. The S series is designed for protective packaging applications. It provides excellent cushioning performance while enabling material savings and cost reduction through higher expansion ratios.
For detailed information on each grade, please contact us. We will be pleased to recommend the most suitable PIOCELAN grade according to your specific requirements."
A highly versatile series offering an excellent balance of cushioning performance and impact resistance, with a proven track record in automotive component applications.
A series designed for further weight reduction through higher expansion ratios, providing superior cushioning performance compared with the O series.
| O series | L series | ||
|---|---|---|---|
| Type | ELV | ENS (Permanent antistatic) | E |
| Expansion ratio (times) | 20 | 15 | 50 |
| 30 | 30 | 60 | |
| Average bead diameter (mm) | 2.7±0.3 | 2.6±0.3 | 5.3±1.0 |
| 3.0±0.3 | 3.0±0.3 | 5.6±1.1 | |
| O series | ||
|---|---|---|
| Type | ELV | ENS (Permanent antistatic) |
| Expansion ratio (times) | 20 | 15 |
| 30 | 30 | |
| Average bead diameter (mm) | 2.7±0.3 | 2.6±0.3 |
| 3.0±0.3 | 3.0±0.3 | |
| L series | |
|---|---|
| Type | E |
| Expansion ratio (times) | 50 |
| 60 | |
| Average bead diameter (mm) | 5.3±1.0 |
| 5.6±1.1 |
* Custom grades other than those listed above are also available. Please contact us for details.
A series that achieves higher expansion ratios while maintaining mechanical strength.
A series featuring higher expansion ratios and self-extinguishing properties. It is well suited for automotive applications.
A series containing recycled materials while maintaining physical properties comparable to those made from virgin materials.
| S series | LW series | RS series | |
|---|---|---|---|
| Type | E | E | E |
| Expansion ratio (times) | 40 | 35 | 5 |
| 50 | 40 | 10 | |
| Average bead diameter (mm) | 4.5±0.6 | 4.5±0.6 | 2.1±0.3 |
| 5.1±0.9 | 4.6±0.7 | 2.7±0.3 |
| S series | |
|---|---|
| Type | E |
| Expansion ratio (times) | 40 |
| 50 | |
| Average bead diameter (mm) | 4.5±0.6 |
| 5.1±0.9 |
| LW series | |
|---|---|
| Type | E |
| Expansion ratio (times) | 35 |
| 40 | |
| Average bead diameter (mm) | 4.5±0.6 |
| 4.6±0.7 |
| RS series | |
|---|---|
| Type | E |
| Expansion ratio (times) | 5 |
| 10 | |
| Average bead diameter (mm) | 2.1±0.3 |
| 2.7±0.3 |
* Custom grades other than those listed above are also available. Please contact us for details.
| Property | Test standard | Unit | O series Type E | L series Type E | ||
|---|---|---|---|---|---|---|
| Expansion ratio | － | Times | 30 | 50 | 60 | |
| Density | g/㎤ | 0.033 | 0.020 | 0.016 | ||
| Compression strength | 25% | ISO-844 | MPa (kgf/㎠) | 0.20 (2.1) | 0.13 (1.3) | 0.11 (1.2) |
| 50% | 0.26 (2.7) | 0.20 (2.0) | 0.18 (1.8) | |||
| Flexural strength | ISO-1209 | MPa (kgf/㎠) | 0.62 (6.3) | 0.44 (4.5) | 0.34 (3.5) | |
| Flexural modulus | MPa (kgf/㎠) | 10.60 (108.2) | 6.20 (63.3) | 4.10 (41.8) | ||
| Tensile strength | ISO-1798 | MPa (kgf/㎠) | 0.53 (5.4) | 0.38 (3.9) | 0.28 (2.8) | |
| Elongation at break | % | 8.2 | 9.7 | 7.6 | ||
| Compression set | ISO-1856 | % | 18 | 16 | 16 | |
| Thermal conductivity 20℃ | ISO-8301 | W/mK (kcal/mh℃) | 0.037 (0.032) | 0.038 (0.033) | 0.039 (0.034) | |
* These data are examples of measurements taken by our company and are not standard values.
| Property | Test standard | Unit | S series Type E | LW series Type E | LW series Type E 黒 | RS series Type E | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Expansion ratio | ― | Times | 40 | 50 | 35 | 40 | 45 | 35 | 40 | 10 | 30 | |
| Density | g/cm3 | 0.025 | 0.020 | 0.028 | 0.025 | 0.022 | 0.028 | 0.025 | 0.100 | 0.030 | ||
| Compression strength | 25% | ISO 844 | Mpa (kgf/cm2) | 0.15 | 0.11 | 0.20 | 0.17 | 0.15 | 0.22 | 0.18 | 0.96 | 0.21 |
| (1.5) | (1.1) | (2.0) | (1.7) | (1.5) | (2.2) | (1.8) | (9.7) | (2.1) | ||||
| 50% | 0.21 | 0.17 | 0.27 | 0.24 | 0.21 | 0.29 | 0.25 | 1.20 | 0.28 | |||
| (2.1) | (1.7) | (2.8) | (2.4) | (2.1) | (3.0) | (2.5) | (12.2) | (2.9) | ||||
| Flexural strength | ISO 1209 | Mpa (kgf/cm2) | 0.35 | 0.26 | 0.50 | 0.44 | 0.40 | 0.48 | 0.43 | 1.47 | 0.59 | |
| (3.6) | (2.7) | (5.1) | (4.5) | (4.1) | (4.9) | (4.4) | (14.9) | (6.0) | ||||
| Flexural modulus | Mpa (kgf/cm2) | 6.10 | 4.60 | 11.60 | 9.52 | 7.99 | 12.12 | 10.16 | 39.90 | 11.30 | ||
| (62.2) | (46.9) | (118.3) | (97.0) | (81.5) | (123.6) | (103.6) | (406.7) | (114.9) | ||||
| Tensile strength | ISO 1798 | Mpa (kgf/cm2) | 0.30 | 0.25 | 0.36 | 0.34 | 0.32 | 0.45 | 0.35 | 1.46 | 0.40 | |
| (3.1) | (2.6) | (3.7) | (3.4) | (3.3) | (4.6) | (3.6) | (14.3) | (4.1) | ||||
| Elongation at break | % | 7.4 | 8.6 | 5.4 | 5.5 | 6.6 | 5.6 | 5.5 | 6.0 | 6.4 | ||
| Compression set | ISO 1856 | % | 18 | 17 | 18 | 18 | 18 | 18 | 18 | 21 | 19 | |
| Thermal conductivity 20℃ | ISO 8301 | W/mK (kcal/mh℃) | 0.037 | 0.038 | 0.037 | 0.037 | 0.037 | 0.037 | 0.037 | 0.043 | 0.037 | |
| (0.032) | (0.033) | (0.032) | (0.032) | (0.032) | (0.032) | (0.032) | (0.037) | (0.032) | ||||
| Property | Test standard | Unit | O series Type E | |
|---|---|---|---|---|
| Expansion ratio | － | Times | 30 | |
| Density | g/㎤ | 0.033 | ||
| Compression strength | 25% | ISO-844 | MPa (kgf/㎠) | 0.20 (2.1) |
| 50% | 0.26 (2.7) | |||
| Flexural strength | ISO-1209 | MPa (kgf/㎠) | 0.62 (6.3) | |
| Flexural modulus | MPa (kgf/㎠) | 10.60 (108.2) | ||
| Tensile strength | ISO-1798 | MPa (kgf/㎠) | 0.53 (5.4) | |
| Elongation at break | % | 8.2 | ||
| Compression set | ISO-1856 | % | 18 | |
| Thermal conductivity 20℃ | ISO-8301 | W/mK (kcal/mh℃) | 0.037 (0.032) | |
| Property | Test standard | Unit | L series Type E | ||
|---|---|---|---|---|---|
| Expansion ratio | － | Times | 50 | 60 | |
| Density | g/㎤ | 0.020 | 0.016 | ||
| Compression strength | 25% | ISO-844 | MPa (kgf/㎠) | 0.13 (1.3) | 0.11 (1.2) |
| 50% | 0.20 (2.0) | 0.18 (1.8) | |||
| Flexural strength | ISO-1209 | MPa (kgf/㎠) | 0.44 (4.5) | 0.34 (3.5) | |
| Flexural modulus | MPa (kgf/㎠) | 6.20 (63.3) | 4.10 (41.8) | ||
| Tensile strength | ISO-1798 | MPa (kgf/㎠) | 0.38 (3.9) | 0.28 (2.8) | |
| Elongation at break | % | 9.7 | 7.6 | ||
| Compression set | ISO-1856 | % | 16 | 16 | |
| Thermal conductivity 20℃ | ISO-8301 | W/mK (kcal/mh℃) | 0.038 (0.033) | 0.039 (0.034) | |
* These data are examples of measurements taken by our company and are not standard values.
| Property | Test standard | Unit | S series Type E | ||
|---|---|---|---|---|---|
| Expansion ratio | － | Times | 40 | 50 | |
| Density | g/㎤ | 0.025 | 0.020 | ||
| Compression strength | 25% | ISO-844 | MPa (kgf/㎠) | 0.15 (1.5) | 0.11 (1.1) |
| 50% | 0.21 (2.1) | 0.17 (1.7) | |||
| Flexural strength | ISO-1209 | MPa (kgf/㎠) | 0.35 (3.6) | 0.26 (2.7) | |
| Flexural modulus | MPa (kgf/㎠) | 6.10 (62.2) | 4.60 (46.9) | ||
| Tensile strength | ISO-1798 | MPa (kgf/㎠) | 0.30 (3.1) | 0.25 (2.6) | |
| Elongation at break | % | 7.4 | 8.6 | ||
| Compression set | ISO-1856 | % | 18 | 17 | |
| Thermal conductivity 20℃ | ISO-8301 | W/mK (kcal/mh℃) | 0.037 (0.032) | 0.038 (0.033) | |
| Property | Test standard | Unit | L series Type E | |||
|---|---|---|---|---|---|---|
| Expansion ratio | ― | Times | 35 | 40 | 45 | |
| Density | g/cm3 | 0.028 | 0.025 | 0.022 | ||
| Compression strength | 25% | ISO 844 | Mpa (kgf/cm2) | 0.20 | 0.17 | 0.15 |
| (2.0) | (1.7) | (1.5) | ||||
| 50% | 0.27 | 0.24 | 0.21 | |||
| (2.8) | (2.4) | (2.1) | ||||
| Flexural strength | ISO 1209 | Mpa (kgf/cm2) | 0.50 | 0.44 | 0.40 | |
| (5.1) | (4.5) | (4.1) | ||||
| Flexural modulus | Mpa (kgf/cm2) | 11.60 | 9.52 | 7.99 | ||
| (118.3) | (97.0) | (81.5) | ||||
| Tensile strength | ISO 1798 | Mpa (kgf/cm2) | 0.36 | 0.34 | 0.32 | |
| (3.7) | (3.4) | (3.3) | ||||
| Elongation at break | % | 5.4 | 5.5 | 6.6 | ||
| Compression set | ISO 1856 | % | 18 | 18 | 18 | |
| Thermal conductivity 20℃ | ISO 8301 | W/mK (kcal/mh℃) | 0.037 | 0.037 | 0.037 | |
| (0.032) | (0.032) | (0.032) | ||||
| Property | Test standard | Unit | L series Type E 黒 | ||
|---|---|---|---|---|---|
| Expansion ratio | ― | Times | 35 | 40 | |
| Density | g/cm3 | 0.028 | 0.025 | ||
| Compression strength | 25% | ISO 844 | Mpa (kgf/cm2) | 0.22 | 0.18 |
| (2.2) | (1.8) | ||||
| 50% | 0.29 | 0.25 | |||
| (3.0) | (2.5) | ||||
| Flexural strength | ISO 1209 | Mpa (kgf/cm2) | 0.48 | 0.43 | |
| (4.9) | (4.4) | ||||
| Flexural modulus | Mpa (kgf/cm2) | 12.12 | 10.16 | ||
| (123.6) | (103.6) | ||||
| Tensile strength | ISO 1798 | Mpa (kgf/cm2) | 0.45 | 0.35 | |
| (4.6) | (3.6) | ||||
| Elongation at break | % | 5.6 | 5.5 | ||
| Compression set | ISO 1856 | % | 18 | 18 | |
| Thermal conductivity 20℃ | ISO 8301 | W/mK (kcal/mh℃) | 0.037 | 0.037 | |
| (0.032) | (0.032) | ||||
| Property | Test standard | Unit | RS series Type E | ||
|---|---|---|---|---|---|
| Expansion ratio | － | Times | 10 | 30 | |
| Density | g/㎤ | 0.10 | 0.03 | ||
| Compression strength | 25% | ISO-844 | MPa (kgf/㎠) | 0.96 (9.7) | 0.21 (2.1) |
| 50% | 1.20 (12.2) | 0.28 (2.9) | |||
| Flexural strength | ISO-1209 | MPa (kgf/㎠) | 1.47 (14.9) | 0.59 (6.0) | |
| Flexural modulus | MPa (kgf/㎠) | 39.90 (406.7) | 11.30 (114.9) | ||
| Tensile strength | ISO-1798 | MPa (kgf/㎠) | 1.46 (14.3) | 0.40 (4.1) | |
| Elongation at break | % | 6.0 | 6.4 | ||
| Compression set | ISO-1856 | % | 21 | 19 | |
| Thermal conductivity 20℃ | ISO-8301 | W/mK (kcal/mh℃) | 0.043 (0.037) | 0.037 (0.032) | |
* These data are examples of measurements taken by our company and are not standard values.
